LM-550A3 Printer
MAX LETATWIN LM-550A3 is a high-speed portable printer for control panel marking, wire numbering, and device labeling. It prints directly on heat-shrink and PVC tubes and MAX polyester tapes.
Key Features
- High speed printing, 40mm/sec
- Print and half-cut at lightning fast speeds
- PC connect with USB, Auto cad data easy transfer
- Large internal memory, large ram 250,000 characters
- Compact and Handy
- Application : Patch Panels, Terminal Blocks, Power Distribution, Automation and Wire harnesses
Download Brochure
Specifications
| Items | Contents |
| Name | ELECTRONIC LETTERING MACHINE LM-550A3 |
| Dimensions | 295(W) x 293(D) x 94(H)mm |
| Weight | 2.3kg |
| Printing Method | Thermal transfer method (300dpi) |
| Display | LCD dot matrix:64 x 160 Pixel(Backlit) |
| Printing Speed | 40mm/s(Standard) 20mm/s(Low temperature mode) |
| Maximum Printing Length | Tube : 100m，Tape :5m When printing multiple copies up to 30 Ferrule (Tube) ;100m, Tape ;7m |
| Maximum number of characters to input | 5,000 characters per file |
| Character size | 1.3 , 2 , 3 , 4 , 6mm height |
| Usable Tube | Ø1.5mm ~ 8.0mm(PVC tube) [or ⌀ 1.5~2.0mm tubes, the dedicated attachment (standard acessory) is required 2.0mm~6.5mm (Heat Shrink tube) |
| Usable Tape | Width 5,9,12mm(Max genuine tape) |
| Usable ID Plate | 2.5/4.1/4.6/6.3/9.0mm wide. *ID Plate Attachment Only compatible with MAX brand 4.1mm wide. |
| Tube Cutting Method | Auto half cut, manual full cut |
| Internal Memory | 250,000 characters (Maximum 50 files) |
| External Memory | USB memory |
| Interface | USB 2.0 full speed |
| Power Supply | DC12V, 3.0A *Use only specified AC Adapter (100V~240V) included in the package |
| Power Consumption | Max 36W |
| Operating Environment | 10°C to 35°C |
